ISO 9001
EN 29001
Installation, Operating, and Maintenance Instructions
Series 021
VAT Vakuumventile AG, CH-9469 Haag, Switzerland
Tel ++41 81 771 61 61 Fax ++41 81 771 48 30 Email reception@vat.ch http://www.vat.ch
205440EC
2003-04-14
9/12
Spare Parts
Seal kit, Actuator service kit, Lubricants
Description Ordering no.
Seal kit, consisting of 1 gate with vulcanized VITON® seal and 1 bonnet seal On request
Spare bellows assembly, 25 x .. / 32 x .. 94196-R1
Spare bellows assembly, 46 x .. / 51 x .. 76610-R1
VAT high temperature pneumatic grease (for piston), 12g N-6951-403
VAT high performance vacuum grease, 10g N-6951-011
Gate with vulcanized VITON® seal, Bonnet seal, Body O-ring at SEMI interface
DN Gate aluminium,
VITON® seal
Gate stainless steel,
VITON® seal
Bonnet O-ring
VITON®
O-ring VITON® at
SEMI interface
Bonnet VATSEAL
(optional, SS body only)
32 x 222 76168-R1 78175-R1 N-5100-266 N-5100-263 82180-01
46 x 236 77006-R1 78201-R1 N-5100-266 N-5100-263 82180-01
50 x 336 94027-R1 96031-R1 N-5100-275 N-5100-273 81697-01
25 x 160 91088-R1 81483-R1 N-5100-262 82588-01
25 x 210 - 81786-R1 N-5100-266 82180-01
25 x 265 - 77008-R1 N-5100-271 77951-01
25 x 420 85113-R1 80664-R1 N-5100-279 92075-01
51 x 160 78819-R1 78493-R1 N-5100-262 82588-01
51 x 210 77939-R1 78213-R1 N-5100-266 82180-01
51 x 265 79364-R1 78485-R1 N-5100-271 77951-01
51 x 420 76752-R1 77682-R1 N-5100-279 92075-01
25 x 254 - 77008-R1 N-5100-271 77951-01
32 x 336 92020-R1 - N-5100-275 N-5100-273 81697-01
Gate/actuator assembly, Valve body, Bonnet flange
Ordering numbers of gate/actuator assembly, valve body (Pos. 60), bonnet flange (Pos. 64), and flange O-ring of custom
made valve body (O-ring size indicated on dimensional drawing) are supplied on request. Please indicate fabrication
number or ordering number and drawing number of the product in question to help identify the required part.
