Chapter 2 SYSTEM OVERVIEW
2.1 System Description
This manual covers the installation and operating procedures of the EzSensor HD(IOS-U20VF,
IOS-U15VF, IOS-U10VF, IOS-U20IF, IOS-U15IF, IOS-U10IF)“collectively or individually referred
to as EzSensor HD or Product”.
Unless otherwise specified, all the information contained in this manual is applicable equally to
all EzSensor HD types.
<Table 1. Specifications >
Parameter Description
Detector Structure CMOS Photodiode Array
Dimensions (W x L x T)
Size 1.0: 1.44 x 1.00 x 0.19 inch (36.8 x 25.4 x 4.8 mm)
Size 1.5:1.55 x 1.15 x 0.19 inch (39.5 x 29.2 x 4.8mm)
Size 2.0: 1.69 x 1.28 x 0.19 inch (42.9 x 31.3 x 4.8 mm)
Pixel Pitch
High Resolution mode : 0.0148 mm
Normal Resolution mode : 0.0296 mm
Active Pixel Array
Size 1.0: 1.18 x 0.79 inch (30.01 x 20.01 mm)
2028 x 1352 pixels @ High Resolution mode
1014 x 676 pixels @ Normal Resolution mode
Size 1.5: 1.30 x 0.94 inch (33.00 x 23.98 mm)
2230 x 1620 pixels@ High Resolution mode
1115 x 810 pixels @ Normal Resolution mode
Size 2.0:1.42 x 1.02 inch (35.99 x 25.99 mm)
2432 x 1756 pixels @ High Resolution mode
1216 x 878 pixels @ Normal Resolution mode
USB Cable length
between Controller and PC
2.7 m
