3. Acquiring PANO Images
24 Green X (PHT-75CHS) User Manual
1. Insert the Normal Bite into the Normal Chinrest and cover it with a Sanitary
Vinyl Cover.
The Sanitary Vinyl Cover is for sole use only. It should be
replaced for each patient. Be sure to use the approved
vinyl cover.
Clean the Chinrest and the Bite with ethanol and wipe with
a dry towel before the next patient.
2. Guide the patient to the inside of the equipment.
3. Use the Column UP/DOWN button in the Touch panel and CEPH part or use the
switch option to adjust the equipment to match the height of the patient.
4. Guide the patient to stand in the center of the equipment and direct them to
remain in the position outlined below.
Hold the handles tightly.
Press the chest against the equipment.
To Next Page
