1. Imaging System Overview
Green X (PHT-75CHS) User Manual 3
English
1. Imaging System Overview
1.1 System Components
 Green X (PHT-75CHS) X-ray equipment
 PC system
 Console Software: PANO, CEPH (Optional), CBCT and 3D MODEL Scan
 EzDent-i: 2D viewer and patient management software
 Ez3D-i: 3D viewer software
1.2 Features
 Multi-FOV support: Selectable FOV among Double Scan(16x15), 16x9, 12x9, 8x8,
8x5, 5x5 and 4x4 (cm)
 The multi-imaging solution for Accurate Diagnostics
 Conventional 2D (PANO and CEPH) image acquisition
 Insight PAN: Multi-image acquisition option that reconstructs the panoramic image
into multiple focal images in depth regions. Its main purpose is to diagnose depth
regions, which cannot be confirmed with ordinary panoramic images.
 3D scanning for Plaster Cast with FOV 8x8 (cm)
 Control Panel implemented for easy use
 DICOM (Digital Imaging Communication in Medicine) format supported
 Differentiated Console Software Interface
 Endo Mode: Provides high resolution CBCT 3D images for root canal treatment
 Double scan: FOV 16×9 images can be acquired by upper/lower double scans
and stitched to acquire full FOV 16x15 CBCT images.
1.3 Imaging System Options
Configuration Item Sensor
SP PANO +CBCT PANO/CBCT Xmaru1314CF
RC
PANO +CBCT
+CEPH
PANO/CBCT Xmaru1314CF
CEPH Xmaru2602CF
