Putting your cleaner together
Feed the cord through the slots on
the back of the handle and push
i
nto place.
Place a nut into the recess in the
back of the upper handle. While
holding the nut in place insert one
of the large screws through the
front of the upper handle and
tighten.
Repeat the process with the second
screw.
Remove the backing tape from the
screw cover and press into place.
1
2 1
Clean water tank
Note: Make sure the cleaning
solution tank is resting in place with
the solution tube pressed fully into
tube opening.
Line up the grooves of the clean
water tank with the support posts
inside the handle. Tilt the top of
clean water tank inward and push
until it locks into place.
To install the tool caddy, line up the
tabs of the tool caddy storage with
round tabs on the back of the
handle (above quick cord clip).
Tool storage
