6
7
2
3
4
Tool storage
Slide the tool caddy
downwards until it is
secured in place.
Note: The tool caddy can
be removed for storage on
a wall.
1
2 3
Pre-treating your carpets
with the carpet treatment
wand and solution
Remove the clean water tank by
pressing the clean water tank
release and pulling the tank by
the handle. Put to one side to fill
later.
While the clean water tank is
removed, loosen the solution tank
by gently pushing out the solution
plug from the plug opening.
Note:
The solution tank can be
filled while it is attached to the
cleaner but you should use care
when refilling.
Remove the solution tank by
pulling up and out.
Note: After spraying rinse the
machine and carpet treatment
w
and with clean w
ater
.
W
ash the
carpet as described in this guide,
using VAX AAA carpet cleaner.
4a
Push the upholstery tool
onto the end of the extra
long stair hose.
Starting on the left of the
machine, wrap the hose around
the back section of the hose
caddy. Wrap the hose around the
back of the machine for a second
and third time, using the front
section of the hose caddy. Secure
in place using the hose clips. To
store the Power Wash Brush,
place on the left hand side of the
machine on the holder provided.
The carpet treatment wand is
stored on the right hand side of
the machine, clipping into place
at both the top and the bottom.
Attach the tube of the carpet
treatment wand into the carpet
treatment wand water supply
port. Press firmly until it locks into
place.
Note: Once the carpet treatment
wand is attached it can remain in
place between uses.
V027(Y) User Guide 5/10/06 11:47 am Page 3
