3 VC72XX Camera Interfaces
The VC72XX Smart Camera incorporates the following connector interfaces:
1. LAN / Ethernet Interface
2. Trigger & Serial (RS232) Interface
3. PLC IO and Power Supply Interface
The pin assignments, electrical specifications as well as available accessories are shown for each
interface connector in the following sections.
LAN / Ethernet Interface
