2.2 Technical Specifications VC7211
Component / Feature Specification
CMOS Sensor: 1/1.8" e2V EV76C560 - also available with color sensor (Bayer Filter)
Active pixels: 1280(H) x 1024(V)
Pixel size: 5.3(H) x 5.3(V) µm
Active sensor size: 6.8(H) x 5.5(V) mm
High-speed shutter: 21 μs + steps of 21 µs
Low-speed shutter: up to 1.35 sec. adjustable integration time
Integration: Global shutter
Picture taking: program-controlled or external high speed trigger, full-frame (50 frames
per second) & partial scanning (up to 4500 fps for 1280x1), jitterfree
acquisition
Parallel image acquisition Not available
Clamping: Internal to sensor
A/D conversion: 100 MHz / 10 bit, only the 8 most significant bits used for grey values
Input LUT none
Image Display Via 100 Mbit Ethernet onto PC
Processor: Texas Instruments TMS320DM6435 “Da Vinci” DSP 700 MHz,
5600MIPS
RAM: 128 Mbytes SDRAM (synchronous dynamic RAM)
Memory capacity: Up to 90 full-size grey value images in format 1280 x 1024
Flash EPROM: 32 Mbytes flash EPROM (nonvolatile memory) for programs and data,
in-system programmable
SD card: n.a.
Process interface: 4 inputs / 4 outputs, outputs 4x400 mA
Trigger: Fast 3.3 V TTL input and output, jitter free image acquisition
Serial Interface: 115,200 bd serial RS232 communication port
Ethernet interface: 10/100 Mbit
CE certification: CE Certification from Vision Components
Storage Conditions Temperature: -20 to 60 deg C, Max. humidity: 90%, non condensing.
Operating Conditions Temperature: 0… +55 deg C, Max. humidity: 80%, non condensing.
Power Supply 24V +/-20% DC, max. 300 mA
Power Consumption ≈2.0W
Lens Mount C Mount with IR-filter
