3.1 LAN / Ethernet Interface
3.1.1 Pin Assignments LAN / Ethernet Interface
Signal
Pin
rear view camera socket:
T+
2
T-
1
R+
6
R-
5
-
3
- 4
3.1.2 Available Accessories for LAN / Ethernet socket
Signal Pin (to cam.) Pin (to PC) Cable Color
20m patch cable
Cable Color
10m patch cable
T+
2
1
yellow
white/pink
T-
1
2
orange
pink
R+
6
3
white/green
white/green
R-
5
6
green
green
-
3
NC
-
-
-
4
NC
-
-
Refer to section 4.2 for a list of available cables with order numbers.
