2.3 Mounting the VDO any-size handlebar holder >>> P04
Step 1 Position the holder socket on the handlebar (stem optionally).
Step 2 Feed the fixing clamp through the slot below the holder socket, pass the clamp
around the handlebar (stem optionally) and tighten it with a little screw driver. Do not
overstress, the plastic screw might be damaged.
2.4 Twist-Click mounting of the computer >>> P05
The VDO Twist-Click-System securely connects the computer with the handlebar holder.
step 1 Hold the computer in the 10 O’clock position (approx. 45° to the left) and place it into
the socket.
step 2 turn the computer to the right “twist” until it engages in the socket.
step 3 for removal turn the computer to the left (do not press or yank)
