53
GB
C1
C2
C3
C4
b. When mounting the sensor on a suspension fork, don’t forget to allow extra length for the
cable.
WATCH OUT: cable may tear
step 1 Loosely attach the sensor on the fork leg with cable ties
(do not tighten yet).
step 2 Mount the magnet on a spoke. Adjust the magnet to the
marking on the sensor (distance 1-5 mm).
step 3 when unit is working, finalize transmitter and magnet
mounting by tightening cable ties and clamping the
magnet
2.2 Mounting cable and VDO “any-size” handlebar holder
step 1 Run the cable up the fork, pass it around the brake cable from the already fixed sen-
sor to the handlebar. Use the enclosed cable ties or duct tape. Spiral the wire around
the brake cable (this has proven to be the best solution).
step 2 position the holder on the handlebar.
