VDO M2.1 WL User Manual

7
M2.1 WL
3
3
4
4


1
2
1
°
Attaching the handlebar bracket
You can attach the computer to the right or left of the handle-
bars or in the centre on the stem. Attach the handlebar
bracket in the corresponding position.
STEP 1
Decide whether you want to attach the computer
to the handlebars or the stem.
STEP 2
Rotate the foot of the handlebar bracket by 90° accordingly.
To do so, undo the screws in the bracket, remove the foot
and rotate it 90° then insert and tighten the screws again.
Attention: do not overtighten the screws.
STEP 3
Guide the cable ties through the slot in the handlebar bracket,
place around the handlebars or the stem and pull (do not pull
tight just yet).
STEP 4
For handlebar attachment: align the computer angle
to achieve optimum readability. Now pull the cable ties tight.
Use clippers to snip off protruding ends.

VDO M2.1 WL Specifications

General

Brand	VDO
Model	M2.1 WL
Category	Bicycle Accessories
Language	English
