VDO Ocean Link - Setting the Inputs; Selection of Fuel Tank Signal

4.1.3 Setting the inputs
(config inputs)
In this menu the following settings are possible:
Fuel tank signal: Selection of fuel quantity signal (see p. 9)
4-20 mA input: Selection of function of 4-20 mA transmitter (see p. 10)
Change boost amount: Setting number of exhaust gas temperature
measured values (see p. 10)
External illumination: Setting of illumination (see p. 10)
4.1.4 Selection of fuel tank signal
Select here from which signal source the fuel tank signal is transmitted:
Off: No display of fuel quantity
CAN: Fuel tank signal from CAN bus
Lever: Fuel tank signal from lever type sensor
Pipe: Fuel tank signal from dip type sensor
When using a dip type sensor, calibration must be carried out. This is always car-
ried out with the tank empty. For this the procedure is as follows:
Example:
Ensure that the tank is empty
DO TANK KALIBRATION ?
YES
TANK IS NOT CALIBRATED
ATTENTION
TANK MUST BE EMPTY
11
Keep key pressed
Keep key pressed
Press key
FUEL TANK SIGNAL
PIPE
DO TANK KALIBRATION ?
NO
TANK IS NOT CALIBRATED
