11. Technical Data
Power supply: 10 to 30 VDC
Current consumption: approx. 120 mA without illumination
approx. 140 mA with illumination
Illumination: red, dimmable, amber display
Operating temperature: - 20 to + 70°C
Type of protection: DIN 40050 –IP 65 front side
EMV: CE according to EMV 83/336/EEC
Data input: CAN 2.0 B; SAE J1939
analogue 4-20 mA
analogue 0-200 Ohm
Data output: VDO Easy Link satellite bus
Dimensions: 85 mm built-in diameter
73 mm built-in depth (including cable)
Connection: Delphi plug, GT 150 sealed
Subject to technical alterations
