6 Vac System Testing - TLS-450PLUS Console Vac Sensor Setup
6-4
PERFORMING VAC SENSOR SETUP
After filling in the Vac Sensor Zone Worksheet, setup each of the Vac Sensors as follows.
1. Go to the Menu>Setup>Devices screen.
Table 6-2.- Vac Sensor Zone Worksheet
Vac Sensor Monitored Zone Description
Address
(Box.Slot.Channel)
(e.g., B1.S1.1)
Calculated Zone Volume
(Gallons)
