1 Introduction Hardware Requirements For Vac Sensors - Verifying Installation
Hardware Requirements For Vac Sensors - Verifying Installation
TLS-350/TLS-350R CONSOLES
•
TLS-350/350R with version 24C or later software
• At least one Smart Sensor with Pressure Sensor Module
• Line leak (PLLD or WPLLD), OR w/o line leak, a Pump Sense and a 4-Relay module is required for STP control.
TLS-450PLUS CONSOLE
•
TLS-450PLUS with version 9B or later software
• At least one Universal Sensor Module (USM) with attached ATM pressure board
• At least one Input/Output Module (IOM) for STP control
STP/TANK
Only V-R supplied vacuum hose (P/N 332310-001, -002, -003) is approved for use with the
SCVS system).
• STP siphon port with Siphon Check Valve (P/N 188-241-5) installed. An external Siphon Check Valve (P/N
188-241-5) must be used when making a vacuum source connection between the SCVS system sensors and
the siphon port cartridge for the following STPs including Red Jacket Standard, Red Jacket Quantum and FE
pumps.
• Schrader Fitting 576008-672 (optional for North American installations; not required for EU - fitting is included)
• Siphon manifolded tank requirements:
- The Red Jacket STP requires a secondary siphon assembly (P/N 410151-001).
- The Quantum STP comes with two siphons as standard equipment - no additional parts are required.
- FE pumps require a secondary siphon kit (FE P/N 402-507-930).
Available Vac Sensor Kits
Vac sensor kits are available in several configurations.
1, 2, 3 or 4 Vac Sensor/Vac Float Pre-Assembled Kits - includes mounting hardware, tubing/connections,
and cables (for one containment sump)
• 1, 2, 3 or 4 Vac Sensor kit w/steel float
• 1, 2, 3 or 4 Vac Sensor kit w/fiberglass 4’, 6’, 8’, or 10’ float (includes relief valve)
• 1,2, 3 or 4 Vac Sensor kit w/o tank interstitial sensor
• 1, 2, 3 or 4 Vac Sensor kits w/o tank float for EU installations (ATEX approved)
Individual Kits (requires Vac Sensor/Vac Float field assembly)
Individual kits require assembly of the Vac Sensor/Vac Float components in the field. V-R
recommends purchasing pre-assembled kits.
