POS App Guide DIM Descriptions
7
DIM And Installation Kit Ordering Guide
Table 2.- Dispenser DIM and Installation Kits
Dispenser
Dispenser
Controller/
POS Type
TLS-350R
DIM P/N
w/Console
TLS-450
DIM P/N
w/Console
TLS-450PLUS
DIM P/N
w/Console
DIM Install Kit
P/N
Console
Compati-
bility
Notes
TLS-350R
TLS-450
TLS-450PLUS
Bennett 92D 330404-040 None 848705-XXX Y N N
For Bennett 92D con-
trollers. DIM kit has 2
CABs in it. One CAB is
needed per current
loop. Only one or two
dispensers are on one
current loop.
Gasboy
CFN2 &
Profit Point
331001-003 None 331088-XXX Y N N
A Gasboy site control-
ler version 2.0 or later
is required. A Gasboy
junction box Gasboy
part # C05020 should
be ordered for installa-
tion. No Blending. Net-
work POS Required.
ANDI,
ALLIED
ANDI,
ALLIED
NEXTGEN
330280-001 Standard In Gauge
None
required
Y Y Y
Allied ANDI. Gilbarco
dispenser with T-14
(Australia). PEC with
8850. POSTEC with
RCC. Wayne with Mar-
keter 2000 (Sweden).
CFN1 331001-002 None 331088-XXX Y N N
This is a TLS-350 RS-
422 interface to the
Network. NOT to be
used for BIR or ISD
applications.
Radiant 330280-001 Standard In Gauge
None
required
Y Y Y
Radiant Systems
Series P1550 set-up
on the TLS must have
a DIM string pro-
grammed in. The DIM
string is B9DNHG and
needs to be pro-
grammed in DIM Diag-
nostics. You will need
to use a twisted pair
RJ-11 cable to the port
on the POS with the
pin outs of 2,3,7.
