POS App Guide DIM Installation Examples
21
Gilbarco TS-1000 POS and PAM Systems
The Veeder-Root Gilbarco TS-1000 DIM and DIM installation kit supports the Gilbarco TS-1000 and any POS
system using the Gilbarco PAM (Pump Access Module) dispenser controller and Gilbarco dispensers.
TLS CONSOLE SOFTWARE REQUIREMENTS
TLS-350R with BIR Software Requirements
• System software Version 17 (or higher)
• DIM software 349634-003C (or later)
TLS-450/TLS-450PLUS with BIR Software Requirements
• TLS-450 System software Version 2.x (or higher)
• TLS-450PLUS System software Version 6.x (or higher)
• BIR option required (TLS-450)
VEEDER-ROOT HARDWARE REQUIREMENTS (REF. TABLE 2)
The following equipment is required to interface the TLS to the TS-1000 POS:
• One Gilbarco Current Loop Dispenser Interface Module for up to 3 current loops
• One installation kit for each current loop
GILBARCO POS AND DISPENSING SYSTEM REQUIREMENTS
• Gilbarco dispenser distribution box, PA02420000000
• Gilbarco dispenser distribution box, PA02610000010
• Gilbarco dispenser distribution box, PA02610000020
• Gilbarco pump controller, model PA02410000000
• Gilbarco Transac System 1000 Console, model PA0240000000
• Gilbarco Transac System 1000 Console, model PA02400001010
• Excentus Reward Fuel Controller™, Gilbarco Dispenser Interface, V1.0.160 (Excentus P/N 080 - Veeder Root
Kit) is required.
SPECIFIC LIMITATIONS
• Up to 48 Gilbarco single product or blending dispenser fueling positions are supported. Dispensers that feature
a blender and a single-product dispenser at one fueling position are not supported.
• Only Gilbarco dispensers are supported.
• In-dispenser credit card readers in these POS systems are not supported by the Gilbarco Current Loop Dis-
penser Interface Module.
• The Gilbarco Current Loop Dispenser Interface Module does not support Gilbarco G-Site applications.
WIRING TO A UNIVERSAL DISTRIBUTION BOX INTERFACE
The diagram in Figure 5 is a typical interconnection diagram for a PAM or Transac System 1000 interface (a
PA0261 distribution box is shown, the PA0241 is slightly different).
