POS App Guide DIM Installation Examples
53
Figure 34. TLS-450/TLS-450PLUS LVDIM Installation With GasBoy 9800 Or Tokheim 2600 Series Electronic Dispenser Head
LVDIM
LOW VOLTAGE DIS PENSER INTERFACE MODULE
+
-
+
-
+
-
+
-
12
11
10
9
+
-
+
-
+
-
+
-
5
6
7
8
+
-
+
-
+
-
+
-
1
2
3
4
+
-
SOURCE
INPUT RATING
30 VDC MAX
0 1 AMP MAX
401-5.eps
GasBoy 9800 or Tokhiem 2600 Series
Electronic Dispenser Head
GasBoy 9800 or Tokhiem 2600 Series
Electronic Dispenser Heads
Not used
Pulse 1 (Red)
NC
Pulse 2 (Grn)
DC Ground (Wht)
DC Junction Box
Set SW1 (on module's PC board)
to the INTERNAL position.
To Other
