● I/O Terminals
Parameter
(address)
Function
Description
Range of settings and definition
Factory default
(setting range)
Notes
F05.00(0x0500)
Terminal X1
function
selection
V/F SVC FVC
See the function of terminal X for details.
1
(0～63)
F05.01(0x0501)
Terminal X2
function
selection
V/F SVC FVC
See the function of terminal X for details.
2
(0～63)
F05.02(0x0502)
Terminal X3
function
selection
V/F SVC FVC
See the function of terminal X for details.
4
(0～63)
F05.03(0x0503)
Terminal X4
function
selection
V/F SVC FVC
See the function of terminal X for details.
8
(0～63)
F05.50(0x0532)
AI lower limit
V/F SVC FVC
Define the signal received by the terminal. The
voltage signal below this value is processed by
the limit value.
0.0%
(0.0%～100.0%)
F05.51(0x0533)
AI lower limit
corresponding
setting
V/F SVC FVC
Set the percentage of the corresponding set
value
0.0%
(-100.0%～
100.0%)
F05.52(0x0534)
AI upper limit
V/F SVC FVC
Define the signal received by the terminal. The
voltage signal above this value is processed
according to the upper limit value.
100.00%
(0.00%～
100.00%)
F05.53(0x0535)
AI upper limit
corresponding
setting
V/F SVC FVC
Set the percentage of the corresponding set
value.
100.00%
(0.00%～
100.00%)
F06.00(0x0600)
AO output mode
selection
V/F SVC
0: 0V～10V
1: 4.00mA～20.00mA
2: 0.00mA～20.00mA
3: Reserved
4: Reserved
0
(0～4)
F06.01(0x0601)
AO output
selection
V/F SVC FVC
0: Given frequency
1: Output frequency
2: Output current
3: Input voltage
4: Output voltage
5: Mechanical speed
0
(0～19)
