SI23 Solar Pump VFD Manual
31
F07.06(0x0706)
Power failure
restart action
selection
V/F SVC FVC
0: Invalid 1: Valid
0
(0～1)
F07.10(0x070A)
Stop mode
V/F SVC FVC
0: Deceleration stop 1: Free stop
0
(0～1)
● Protection Parameters
Parameter
(address)
Function
Description
Range of settings and definition
Factory default
(setting range)
Notes
F10.00(0x0A00)
Overcurrent
suppression
V/F SVC FVC
The automatic limiting output current does not
exceed the set overcurrent suppression point to
prevent overcurrent faults from being triggered
by excessive current.
0: Inhibition is always valid
1: Acceleration/deceleration is valid, constant
speed is invalid
0
(0～1)
F10.01(0x0A01)
Overcurrent
suppression
point
V/F SVC FVC
Set the load current limit level, 100%
corresponds to the rated motor current.
160.0%
(0.0%～300.0%)
F10.12(0x0A0C)
Bus overvoltage
suppression
point
V/F SVC FVC
Set bus voltage value for trigger overvoltage
suppression function.
T3: 780
S2: 370
(T3: 650～760
S2: 340～380)
Also subject to
overvoltage limit
T3
overvoltage
point: 820V
(750～840)
S2
overvoltage
point: 400V
(360～410)
F10.16(0x0A10)
Bus
undervoltage
suppression
V/F SVC FVC
When the bus voltage is lower than the
undervoltage suppression point, the operating
frequency is automatically adjusted to suppress
the bus voltage from decreasing, preventing the
undervoltage fault.
0: Off 1: On
0
(0～1)
F10.17(0x0A11)
Bus
undervoltage
suppression
point
V/F SVC FVC
Set bus voltage value for trigger undervoltage
suppression function.
T3: 430
S2: 240
(T3: 350～450
S2: 180～260)
Also subject to
overvoltage limit
T3
overvoltage
point: 820V
(750～840)
S2
overvoltage
point 400V
(360～410)
