SI23 Solar Pump VFD Manual
36
● Fault Monitor
Parameter code
(address)
Function Description
Content
Signal level of
multi-function
analog output
Notes
C01.00 (0x2200)
Fault type diagnostic information
V/F SVC
C01.01 (0x2201)
Troubleshooting information
V/F SVC
C01.02 (0x2202)
Fault operating frequency
V/F SVC
C01.03 (0x2203)
Fault output voltage
V/F SVC
C01.04 (0x2204)
Fault output current
V/F SVC
C01.05 (0x2205)
Fault bus voltage
V/F SVC
C01.06 (0x2206)
Faulty module temperature
V/F SVC
C01.07 (0x2207)
Faulty VFD status
V/F SVC
C01.08 (0x2208)
Fault input terminal status
V/F SVC
C01.09 (0x2209)
Fault output terminal status
V/F SVC
● I/O Terminals Function Table
X
Functional interpretation
X
Functional interpretation
X
Functional interpretation
0
No function
21
PID control pause
42
Counter clock input terminal
1
Forward running
22
PID characteristic switching
43
Counter clear terminal
2
Reverse run
23
PID parameter switching
44
DC brake command
3
Three-wire operation control
(Xi)
24
PID given switch 1
45
Pre-excitation command
terminal
4
Forward turn
25
PID given switch 2
46
Reserved
5
Reverse jog
26
PID given switch 3
47
Reserved
6
Free parking
27
PID feedback switching 1
48
Command channel switch to
keyboard
7
Emergency pull over
28
PID feedback switching 2
49
Command channel switch to
terminal
8
Fault reset
29
PID feedback switching 3
50
Command channel switch to
communication
9
External fault input
30
Program run (PLC) pause
51
Command channel switch to
expansion card
10
Frequency increment (UP)
31
Program run (PLC) restart
52
Run prohibition
11
Frequency decrement (DW)
32
Acceleration/deceleration time
selection terminal 1
53
Forward prohibition
12
Frequency increment
decrement clear (UP/DW
clear)
33
Acceleration/deceleration time
selection terminal 2
54
Reverse prohibition
13
Channel A switches to
channel B
34
Suspension acceleration
55
Reserved
14
Switch the frequency channel
combination to A
35
Swing frequency input
56
Reserved
15
Switch the frequency channel
combination to B
36
Swing frequency pause
57
Zero servo command
16
Multi-speed terminal 1
37
Swing frequency reset
58
Run output blocking
command
17
Multi-speed terminal 2
38
Keyboard button and display
self-test selection
80
Water fulfilled detection alarm
18
Multi-speed terminal 3
39
X4 frequency measurement
81
Water fulfilled detection reset
