SI23 Solar Pump VFD Manual
35
3: (N, 8, 2) no parity,
Data bits: 8,
Stop position: 2
4: (E, 8, 2) even parity,
Data bits: 8,
Stop position: 2
5: (O, 8, 2) odd parity,
Data bits: 8,
Stop position: 2
● Monitoring parameters
Parameter code
(address)
Function Description
Content
Signal level of multi-function analog output
Notes
C00.00 (0x2100)
Given frequency
V/F SVC
10V corresponds to the maximum frequency
(60Hz)
C00.01 (0x2101)
Output frequency
V/F SVC
10V corresponds to the maximum frequency
C00.02(0x2102)
Output current
V/F SVC
10V corresponds to the rated current of the
double motor (5A)
C00.03 (0x2103)
Input voltage
V/F SVC
10V corresponds to 380V
C00.04 (0x2104)
The output voltage
V/F SVC
10V corresponds to the rated voltage of the
motor 360V
C00.05 (0x2105)
Mechanical speed
V/F SVC
10V corresponds to the maximum frequency of
mechanical speed
C00.08 (0x2108)
PID given
V/F SVC
10V corresponds to 100%
C00.09 (0x2109)
PID feedback
V/F SVC
10V corresponds to 100%
C00.10 (0x210A)
Output Power
V/F SVC
C00.11 (0x210B)
Bus voltage
V/F SVC
5V corresponding rated bus voltage
C00.12 (0x210C)
Module temperature 1
V/F SVC
10V corresponds to 100℃
C00.14 (0x210E)
Input terminal X is on
V/F SVC
C00.15 (0x210F)
Output terminal Y is on
V/F SVC
C00.16(0x2110)
Analog AI input value
V/F SVC
10V corresponds to 10V
C00.20 (0x2114)
Analog output AO
V/F SVC
C00.23 (0x2117)
Power-on running time
V/F SVC
C00.24 (0x2118)
Accumulated running
time of the machine
V/F SVC
C00.25 (0x2119)
VFD power level
V/F SVC
C00.26 (0x211A)
VFD rated voltage
V/F SVC
C00.27 (0x211B)
VFD rated current
V/F SVC
C00.28 (0x211C)
Software version
V/F SVC
