SI23 Solar Pump VFD Manual
34
keyboard
00～63.
LED "000" and "0000" digit: Monitoring
parameter number Cxx.yy xx setting
00～07.
F11.14(0x0B0E)
Parameter 4
showed up on
first line of the
keyboard
V / F SVC
LED "0" and "00" digit: Monitor parameter
number Cxx.yy YY setting
00～63.
LED "000" and "0000" digit: Monitoring
parameter number Cxx.yy XX setting
00～07.
0011
(0000～0763)
F11.20(0x0B14)
Keyboard
display item
settings
V/F SVC FVC
LED "0" digit: Output frequency display
selection.
0: Target frequency
1: Operating frequency
LED "00" digit: Reserved.
0: Invalid
1: Active power to remove stator resistance loss
LED "000" digit: Power Display Dimensions.
0: Power display percentage (%)
1: Power display kilowatt (kW)
LED "0000" digit: Reserved
0000
(0000～1111)
● Communication Parameters
Parameter
(address)
Function
Description
Range of settings and definition
Factory default
(setting range)
Notes
F12.00(0x0C00)
Master-slave
choice
V/F SVC FVC
0: Slave
1: Host
0
(0～1)
F12.01(0x0C01)
Modbus
communication
address
V/F SVC FVC
1
(1～247)
F12.03(0x0C03)
Modbus data
format
V/F SVC FVC
0: (N, 8, 1) no parity,
Data bits: 8,
Stop position: 1
1: (E, 8, 1) even parity,
Data bits: 8,
Stop position: 1
2: (O, 8, 1) odd parity,
Data bits: 8,
Stop position: 1
0
(0～5)
