1 Adjusting the steam volume
Turning the handwheel adjusts the steam volume.
VEIT recommends to open the handwheel by 90°.
2 Control panel
n Standard version Ä Chapter 7.1.1 ‘Control
panel on standard version’ on page 36
n Cleaning version
Ä Chapter 7.1.2 ‘Control
panel on cleaning version’ on page 37
3 Filling nozzle for VEIT SteamClean
VEIT SteamClean can be refilled via the filling
nozzle, if required.
For cleaning version only.
4 Steam pressure (pressure gauge)
Displays the current boiler pressure.
5 Water filling opening
Feedwater can be refilled via the water filling
opening.
6 Blow-down valve
When opening the blow-down valve, the blow-down
water is discharged during blow-down.
7 Vent valve
If the pump does not supply water, the vent valve
must be opened to vent the pump.
