SPECIFICATIONS
12
BLUETOOTH
BT: 5.0
BT Range: 33FT / 10 M (CLASS 2)
BT Profiles: A2DP
AMPLIFIER
Channels: 2 Class D
MAX Continuous Output: 150W x 2 Peak @4ohm speaker
PEAK Power Rating
RMS Total Power Output: 150W x 2
Class AB
Bridgeable to 300W x 1 peak @ 8ohm speaker, only for professional
Frequency response: 20-20KHz
4 Ohm stable
Input impedance: 22K Ohm
CHASSIS
Dimension: W x L x H
99 x 203 x 50 mm
Controller Dimensions W x L x H
47 x 95 x 22 mm
Controller cable length: 3m
Quick connect Molex power harness
GENERNAL
Power source: 14.4VDC (10.8 16V Allowable)
Grounding System: Negative type
Maximum Current Consumption: 20A
3-way protection circuitry (thermal, overload, and speaker short protection)
USB output voltage: 5VDC @1A
Unit weight: 2.08lbs / 0.94kgs
Storage Temperature: 5 F to 113 F / - 15 to 45 degree
Replacement Fuse: 10A
(Replace with ATO Fuse Type Only).
