Velex VX508 - Wire Diagram

WIRE DIAGRAM
CAUTION!! Do not ground or short the PINK antenna wire
3
WHITE
WHITE/BLK
+
-
RMS 150W
4-OHM
SPEAKERS
LEFT
CHANNEL 1
GRAY
GRAY/BLK
+
-
RIGHT
CHANNEL 1
REMOTE OUT
(500mA MAX)
+12V BLUE
+12V RED IGNITION
+12V YELLOW
BATTERY
FUSE REPLACEMENT
BATTERY
CHASSIS
GROUND
POINT
DIRECT BATTERY
WIRING CIRCUIT
PINK
ANTENNA
(DO NOT CUT)
BLACK
CHASSIS
GROUND
PIONT
VX502
SRC
INSERT
REMOTE
CONTROL
USB CHARGING
(1A MAX)
(R) INPUT RED
(L) INPUT WHITE
RCA TO 3.5mm
ADAPTOR
NOT INCLUDED
1
14
10 AMP
BLK
BLACK
10 AMP
