Velodyne DIGITAL DRIVE SERIES User Manual

Package Contents
2
.
www.velodyne.com
Digital Drive User’s Manual
Your Velodyne Digital Drive Subwoofer consists of the following components:
• Digital Drive Subwoofer
• Power Cord
• Remote Control
• Digital Drive Accessor
y Kit, consisting of:
- Calibrated precision microphone
- Microphone windscreen cover
- Tabletop microphone stand
- Microphone stand adapter
- 25-foot video cable
- 25-foot audio cable
- 20-foot XLR microphone cable
SUBWOOFER
Prominent features of your new Digital Drive Subwoofer include:
• Cone and Motor sizes:
- 10” (8” Piston Diameter) or 12” (9.7” Piston Diameter) cone with 310 oz. magnet or,
- 15” (12.7” piston diameter) or 18” (15.2” piston diameter) cone with 380 oz. magnet
• Built-in 1250 watt (RMS), 3,000 watt peak power high-efficiency Class-D amplifier
• T
andem 3” voice coils
• Multi-layer resin laminate cone
• High-excursion rubber surround
• Gain compression, anti-clipping circuit to prevent over excursion and amp clipping
• Fixed 80Hz high-pass crossover (RCA output)
• Balanced (XLR) input
• Line-level (RCA) inputs and thruputs
• Speaker-level inputs
• V
ariable volume control
• Frequency response of 20Hz - 120Hz +/-3dB
• Detachable 6-foot AC power cord
• Four rubber 1/4” --20” threaded suppor
t feet (aluminum with rubber inserts
on 15” and 18” models)
• On-screen controls:
- Auto-EQ
- Graphic or Parametric Equalizer controls for room EQ
- Adjustable (15 Hz - 199 Hz) low-pass crossover (defeatable)
- Multiple staggered low-pass crossovers (6dB/octave, initial to 48dB/octave, ultimate)
- Adjustable (15Hz - 35Hz) subsonic filter (defeatable)
- Multiple staggered subsonic filters (12dB/octave, initial to 48dB/octave, ultimate)
- Variable volume control
- Adjustable phase control (0° - 180° in 15° increments)
- Selectable polarity (+/-)
Product Features and Controls
