HDL-64E User’s Manual
DSR Key Controls
Zoom:
Z = Zoom in
Shift, Z = Zoom out
Z axis rotation:
Y = Rotate CW
Shift, Y = Rotate CCW
X axis rotation:
P = Rotate CW
Shift, P = Rotate CCW
Y axis rotation:
R = Rotate CW
Shift, R = Rotate CCW
Z Shift:
F = Forward
B = Back
X Shift:
L = Left
H = Right
Y Shift:
U = Up
D = Down
Aux. Functions:
Ctrl, (Z,Y,P,R,F,B,L,H,U,D) Direction = Fine Movement
Alt, (Z,Y
,P,R,F,B,L,H,U,D) Direction= Very Fine Movement
DSR Mouse Controls
Rotational:
Left Button/Move
Slide:
Right Button/Move
Zoom:
Scr
oll for
ward = Zoom In
Scroll backward = Zoom Out
