9. Appendix
9-2
ROBOT HP7C / HP10C / HP15C / HP17C
© VEMAG 2004
9.2 Technical data ROBOT HP7C / HP10C / HP15C / HP17C
Filling output HP7C: up to 3,800 kg/h
(depends on feed element)
HP10C: up to 5,800 kg/h
(depends on feed element)
HP15C: up to 14,000 kg/h
(depends on feed element)
HP17C: up to 6,000 kg/h
(depends on feed element)
Portion size: 5 - 60,000 g adjustable in increments of
0.1 g or 1 g
Portion speed: > 700 portions/min. (depends on product,
casing and portion size)
Number of links: 0 - 10, infinitely adjustable
Vacuum pump rating: 15 m³/h
Hopper capacity: 250 l/350 l (optional)
Height adjustable by: 80 mm (1,000 - 1,080 mm)
Total weight including lifting/
tipping device (optional): approx. 1,300 kg
Noise emission: < 75 dB (A)
Total nominal HP7C: 9.5 kW at 50 Hz / 12 kW at 60 Hz
output HP10C: 13 kW at 50 Hz / 60 Hz
HP15C: 17 kW at 50 Hz / 60 Hz
HP17C: 17 kW at 50 Hz / 60 Hz
Main motor HP7C: 7,5 kW at 50 Hz / 12 kW at 60 Hz
HP10C: 11 kW at 50 Hz / 60 Hz
HP15C: 15 kW at 50 Hz / 60 Hz
HP17C: 15 kW at 50 Hz / 60 Hz
Mains voltage Frequency Nominal current Back-up fuse
HP7C/HP10C: 380 - 400 V 50 Hz 21 A 35 A
220 - 230 V 50 Hz 36 A 63 A
380 - 460 V 60 Hz 20 A 35 A
220 - 265 V 60 Hz 35 A 63 A
HP15C/HP17C: 380 - 400 V 50 Hz 27 A 50 A
220 - 230 V 50 Hz 47 A 80 A
380 - 460 V 60 Hz 25 A 50 A
220 - 265 V 60 Hz 46 A 80 A
Electrical fittings: to DIN EN 60204-1
Protection (exterior): IP 65
Protection (interior): IP X3
Type of mains connection for TNS mains equipment protection class I
(earth wire)
