9.4 Vacuum system
1 Vacuum pump 5 Vacuum display
2 Air filter in intake line 6 Vacuum pot
3 Intake line 7 Float valve
4 Vacuum control valve 8 Exhaust air hose
1
6
2
7
5
3
4
8
