9. Appendix
9-11
ROBOT HP7C / HP10C / HP15C / HP17C
© VEMAG 2004
9.9.2 Filling horn selection
The following filling horns are available for straight filling.
Horn dia. Filling horns Filling horns with
ø to DIN 9798 crowned outlet
8 901.100.080 -
9 901.100.090 -
10 901.100.100 -
12 901.100.120 -
13 901.100.130 -
14 901.100.140 -
15 901.100.150 -
16 901.100.160 901.500.160
18 901.100.180 901.500.180
20 901.100.200 901.500.200
22 901.100.220 901.500.220
24 901.100.240 901.500.240
28 901.100.280 901.500.280
30 901.100.300 901.500.300
35 901.100.350 901.500.350
40 901.100.400 901.500.400
45 901.100.450 -
50 901.100.500 -
55 901.100.550 -
60 901.100.600 -
9.9.3 Linking horns
The linking horn should be selected as a function of the casing holding
device used. To select a suitable linking horn
Casing holding device / Length portioning device operating
instructions
9.9.4 Miscellaneous accessories
Component Use Order no.
Filling horn holder for 367 mm double screws 936.315.000
Filling horn holder for 454 mm double screws 936.316.002
Filling horn nut for attaching filling horn 930.100.017
Vacuum plug vacuum opening 143.500.510
Cleaning plug vacuum line intake pipe 142.300.600
