VEND MECHANISM PARTS DESCRIPTION
The parts listed below are part of the vend motor mechanism (refer to Figure 10 on
page G-9). One mechanism is required per column. The parts are interchangeable.
Setting will differ between single, double, triple, and quadruple depth.
VEND MOTOR ASSEMBLY: P/N 1115821
The motor is attached to the mech plate by three screws.
TIMING CAM: P/N 1113236; RETAINER: P/N 1113244
The motor cam assembly consists of two parts, the cam and the cam retainer. The cam
controls the vend cycle. The cam is attached to the motor by the cam retainer. The
retainer rotates left or right, and provides for single, double, triple, or quadruple depth
operation.
SOLD-OUT SWITCH: P/N 368299
There is one sold-out switch above the vend motor. The sold-out switch is actuated by
the sold-out flap when the column is empty. It prevents the motor from running when
the columns are empty.
VEND BUCKET: P/N 1120146
The vend bucket holds the product(s) in a “ready to vend” position at the base of each
column.
MOTOR COUPLING: P/N 1076465
The adapter coupling couples the motor to the bucket. It is located behind the motor, on
the motor shaft.
ANTI-THEFT CLIP: P/N 389712
The anti-tilt clip prevents product from dropping out of the bucket if the vendor is tilted.
The anti-theft clips are located in the bucket.
GATE: P/N 1121282
The gate holds product above the vend bucket.
