3/2002
PC-9
SET-UP AND CODE DESCRIPTION (CONTINUED)
Space-to-Sales Setting Mode
If any selection button is pressed at the “SSSS” prompt, the controller will enter the Space-
to-Sales option. Upon entry into this setting the display will show the current option setting.
Pressing any selection button for 3 seconds will change the space-to-sales configuration as
listed below. The display will show “STS nn” where “nn” indicates the desired option.
SSSS
For proper configuration settings refer to the label located on the inner door shear
panel (See figure 3)
SPACE-TO-SALES CONFIGURATIONS
ST10 STS9 STS8 STS7 STS6 STS5 STS4 STS3 STS2 STS1
SEL# COL COL COL COL COL COL COL COL COL COL
1 1 1,2 1 1 1,2,3 1,2 ~ ~ ALL NONE
2 2 1,2 2 2 1,2,3 1,2 ~ ~ ALL NONE
3 3 3 3 3 1,2,3 3 ~ ~ ALL NONE
4 4 4 4 4 4 4 ~ ~ ALL NONE
5 5 5 5 5 5 5 ~ ~ ALL NONE
6 6 6 6 6 6 6 ~ ~ ALL NONE
7 7 7 7 7 7 7 ~ ~ ALL NONE
8 8 8 8 ~ 8 8 ~ ~ ALL NONE
9 9 9 ~ ~ 9 ~ ~ ~ ALL NONE
10 10 10 ~ ~ 10 ~ ~ ~ ALL NONE
FIGURE 3
Note: If none of the space-to-sales configurations are suitable, the operator can use the
Custom Space-to Sales Setting Mode.
Custom Space-to-Sales Setting mode
If any selection button is pressed at the “CSSS” prompt, the controller will enter the Custom
Space-to-Sales option. Upon entry into this setting the display will show the current selection
setting followed by the columns connected to that selection button.
SSS
Programming Connection Option
If any selection button is pressed for more then 3 seconds while at the “CSSS” prompt the
controller will enter the Custom Space-to-Sales Programming Option. Pressing selection
button one or two will increase or decrease the column number displayed. Pressing
selection button three will actuate the changed connection status of the column number
displayed. Pressing selection button four will save the connection changes and return the
controller to the “CSSS” prompt.
