3/2002
PC-8
SET-UP AND CODE DESCRIPTION (CONTINUED)
Option Group 1 Mode
OPt1
If selection button one is pressed at the “OPt1” prompt, the controller will enter the Option
Group 1 Mode. The purpose of this mode is to allow the controller to select the group 1
configuration options desired. Upon entry into this setting the display will show “1.1 y”
where “y” is for enable or “n” for disable. Pressing selection buttons 1-5 will display the
available options listed below.
EXAMPLE: “1.1 y” = Option group 1 enabled
“1.1 n” = Option group 1 disabled
Selection
No.
Display Description
Button #1 1.1 “y” or “n” Force vend enabled (y) or disabled (n)
Button #2 1.2 “y” or “n” Bill Escrow enabled (y) or disabled (n)
Button #3 1.3 “y” or “n” Error/Sold Out indicator “o” enabled (y) or
disabled (n)
Button #4 1.4 “y” or “n” Single Price enabled (y) Multi-Price enabled (n)
Button #5 1.5 “y” or “n” Sales count by price is enable/ By selection is
disable if “Y” = “Yes”
Sales count by selection is enable/ By price is
disable if “N” = “No”
Button #6 Toggle software info. Displays controller and software version
Option Group 2 Mode
If selection button one is pressed at the “OPt2” prompt, the controller will enter the Option
Group 2 Mode. The purpose of this mode is to allow the controller to select the group 2
configuration options desired.
OPt2
Selection No. Display Description
Button #1 2.1 “y” or “n” “Y”- Correct change light indicator is disabled.
“N”- Correct change light indicator operates as
normal.
Button #2 2.2 “y” or “n” Allow Overpay enabled (y) or disabled (n)
Button #3 2.3 “y” or “n” “Y” - Save Credit Timer is enabled holds credit
for 5 minutes.
“N” - Save Credit Timer is disabled in which
credit never times out.
Button #4 2.4 “y” or “n” Multi-vend enabled (y), Single vend enabled (n)
To Next Page
