2.0 Service (cont’d)
2.2 Parts Ordering Chart for Venmar 1.3 HE,
Venmar 3055 Compact, Venmar 5585 Compact and vänEE 1000 HE
No Description Venmar Venmar Venmar vänEE
1.3 HE 3055 Compact 5585 Compact 1000 HE
1 Double Collar 6” 02021 02021 02021 02021
2 Single Collar 6” 00867
2 Single Collar 7” 01177 01177 01177
3 Plastic Hole Plug 1/2” 01581 01581 01581 01581
4 Strain Relief Bushing SR-7K-2 00660 00660 00660 00660
5 Strain Relief Bushing SR-2M-4 00525 00525 00525 00525
6 Insulated Damper 12459 12459 12459 12459
7 Insulated Rect. Damper 12460 12460 12460 12460
8 Shaft Assembly 02023 02023 02023 02023
9 Damper Motor Rod 2.812” 11891 11891 11891 11891
10 Rubber Grommet #2852 00248 00248 00248 00248
11 Damper Motor Rod 5.250” 11892 11892 11892 11892
12 Thermistor Kit 12895 12895 12895 12895
13 Machine Screw 6-32 x 3/8” 00080 00080 00080 00080
14 Electronic Board 02168 & 12606 02168 & 12606 02168 & 12606 02168 & 12606
15 Machine Screw 10-24 x 1 1/4” 00083 00083 00083 00083
16 Nylon Spacer 1/4” DIA. x 1” #6-32 00703 00703 00703 00703
17 Lock Nut #10-24 01689 01689 01689 01689
18 Core 13.5” x 13.5” x 13” 01817 01403 01403
18 Core 13.5” x 13.5” x 7.875” 01402
19 Filter 12 15/16” x 13 1/2” x 3/8” 01234 01234 01234
19 Filter 7 13/16” x 13 1/2” x 3/8” 01232
20 Door Assembly 13395 13395 13395 12662
21 6W Damper Actuator Assembly 02017 02017 02017 02017
22 Plastic Soft Joint 02031 02031 02031 02031
23 Nylon Washer 0.875” ID x 1.750”OD 02059 02059 02059 02059
24 3055 Cent. Wheel 6.29” DIA. (right) 02015
24 Wheel 6.290” DIA. x 2.396” (right) 03093 03093
24 Dble Cent Wheel 7.062”DIAx1.31”(rght) 02014
25 Anchor Nut 01333 01333 01333 01333
26 Hex. Screw 14 x 5/8” T/A 01470 01470 01470 01470
27 Motor and Installation Kit 12027 12027 12026 12027
28 Capacitor Bracket 01544 01544 01544 01544
29 Capacitor 00683 00683 00683 00683
30 Front Housing 01180 01190 01180 01180
31 Wheel 6.3” DIA. x 3.6” (left) 12108
31 Wheel 7.125” DIA. x 2” (left) 02240 02240
31 Wheel 7.125” DIA. x 2.5” (left) 01178
32 Door latch Assembly 00886 & 00887 00886 & 00887 00886 & 00887 00886 & 00887
Please take note that parts not listed are not available; those parts require assembly knowledge that only manufacturer can guarantee.
TO ORDER PARTS: Contact your local distributor.
