Venmar 41552 - Service Parts

13
For the Installer
NO.DESCRIPTION
PART
NO.
41550 41552 41650 41652 41554 41556 41654 41656
41500
41502 41504 41506
41600
41602 41604 41606
1 Oval port (fits 5” diameter ducts) 16040 1111111111111111
2 Door latch with screws 16035 2222222222222222
3
Oval port with integrated
balancing damper
16041 2222222222222222
4
Motor & wheel assembly
(5 μF motor capacitor and inlet
ring included)
183012222222222222222
5 Capacitor 5 μF (Qty.: 2) 16042 1111111111111111
6 Capacitor 18 μF 61127 1111111111111111
7 Electronic board
62257 11111111
16038 11111111
8 ERV foam filter (2) 16031 1111 11 11
9 ERV core (incl. 2 filters) 16033 1111 11 11
10 Drain connector kit 03203 1111
11 Door assembly
16094 1 1 1 1 1111
16095 1 1 1 1 1111
12 HRV core (with 2 foam filters) 18300 1111 11 11
13 HRV foam filter (Qty.: 2) 16032 1111 11 11
14 Motorized damper port assembly 16029 1111111111111111
* ES Transformer 18302 1111111111111111
* PCB Connector 16416 1111111111111111
* N
OT SHOWN.
9. SERVICE PARTS
VL0053
1
2
3
4
7
5
6
11
12
13
3
14
8
9
10
