13
For the Installer
7.1.3 LITE-TOUCH CONSTRUCTO, SIMPLE-TOUCH CONSTRUCTO,
LITE-TOUCH BRONZE OR SIMPLE-TOUCH BRONZE
7.1.4 CONSTRUCTO OR BRONZE
NO C NC I OC OL Y R G B
BG
G
B
Y
VE0328A
Y
NO C NC I OC OL Y R G B
VE0323
--5°C
23°F
5
°
C
41
°
F
C
O
M
F
O
R
T
Z
O
N
E
-20°C
-4°F
OFF
MIN MAX
#
X
X
X
X
X
0
1
/
9
8
7.1.5 OPTIONAL AUXILIARY CONTROLS
Once the control(s) connections have been made, insert the terminal connector in the electrical
compartment interface.
NO C NC I OC OL Y R G B
20/40/60-MINUTE or 20-MINUTE
PUSH-BUTTON SWITCHES
(5 MAXIMUM)
60-MINUTE
CRANK TIMER
VE0089A
DEHUMIDISTAT
VE0221
TERMINAL
CONNECTOR
7.2 SETTING EXTENDED DEFROST
These units are factory set to normal defrost. In cold region (outside temperature -27°C [-17°F] and lower), it may be necessary to setup
extended defrost. During the first 2 seconds of the booting sequence, while the integrated control LED is GREEN, press on push button for
3 seconds to set the unit in extended defrost; the LED will blink AMBER to show the unit is in extended defrost mode. After that, the LED
will shut off, and turn RED (the unit resumes its booting sequence).
