Venmar VCS500 SERIES User Manual

4
2. SELECT INSTALLATION TYPE (CONT'D)
Refer to illustrations below to locate duct opening according to discharge type chosen (grey parts to be installed later).
3. REMOVE GREASE FILTERS
Rest the range hood on a table. Remove tapes on
filters. Remove filters from range hood by pushing
them down and tilt, then set aside the filters.
Remove both styrofoam pieces and tape from
under the blower and discard.
12¾”
14
15
/16”
C
L
9¾”
HK0203A
6
7
/16”
11
15
/16”
17
15
/16”
24”
WIDTH HOOD
30” WIDTH HOOD
36” WIDTH HOOD
3¼”
3”
2
7
/8”
C
L
9¾”
HK0202A
14
15
/16”
11
15
/16”
17
15
/16”
24”
WIDTH HOOD
30” WIDTH HOOD
36” WIDTH HOOD
3¼”
15/16”
VERTICAL DISCHARGE
HORIZONTAL DISCHARGE
4. CHOOSE THE OPENING
FOR VERTICAL DISCHARGE:
Remove the knockout in order to clear vertical discharge opening (see illustration beside).
HR0122
6” DIA.
C
L
HK0201A
14
15
/16”
11
15
/16”
17
15
/16”
24”
WIDTH HOOD
30” WIDTH HOOD
36” WIDTH HOOD
VERTICAL DISCHARGE
HD0811
2
1
VCS500
HD0812
2
1
VCS550
