Page 60
Installation and Operation Manual - HE275CF
ENGLISH
C) Secure the telescoping sections (D) to the heat distribution box (C) with self-tapping screws
(G) (3 per telescoping section). Determine the needed height and secure the two parts of the
telescoping sections together with 3 self-tapping screws. Insert the adjustable frame (B) in the
heat distribution box (C), press it against the non-combustible material and secure with 4 screws
into the heat distribution box. Set the decorative plate (A) to the adjustable frame (B).
A
B
C
6X
G
D
