VeriFone T650p - Getting started with your new terminal; Terminal layout and features

DEVICE OVERVIEW
8 T650P INSTALLATION GUIDE
Key Features and Benefits
Processor • Cortex A7 Quad Core, 1.1GHz
• (QCOM 8909)
Memory
• 2 GB RAM/16 GB ROM
• 32 GB SD
Display • 5.5" (1280 × 720) HD IPS LCD touchscreen
• Screen rotation
Keypad
• On-screen, Navigator possible
Payment • MSR
• SCR
• CTLS
• QR Code
Multimedia
• Speaker and audio jack and Volume Buttons
• Integrated microphone
• Video HD
• Video Decode
Communication • Bluetooth 4.2 BLE
• 2.4 GHz + 5 GHz WiFi
• 802.11 b/g/n
GPS
• GPS, GLONASS
Physical Interface • USB port type C
Camera/Barcode
Scan
• 5 MP (forward QR/Barcode Scanner)
• Embedded forward facing camera - 5MP
• Front facing camera - 2MP
Dimensions • Length: 208 mm
• Width: 84 mm
• Height: 64 mm
• Weight: 363 g
Security
• PCI PTS 5.X-approved
• SRED
• Supports AES DUKPT
Power adaptor • Input: AC 110V~240V/50~60Hz/0.3A
• Output: DC 5V/2A
Battery
• standard configuration 2600mAh/7.2V
