VeriFone Vx520 Operation Procedure

 The screen reads ‘Print Cust Copy’ , prompting the merchant to select
F1 – Yes
F2 – No
 The receipt is generated once “Yes” is selected and then reads ‘Return Customer Card’
 Press “Cancel” ( red key ) to revert to the ‘Home Screen’
Note
1. The Process of Voiding/Reversing a transaction is the same for Debit Transactions, Credit Card
(Magstrip/Non-Chip) Transaction and Credit Card (Chip Card) Transactions.
7

VeriFone Vx520 Specifications

General

Peripheral Ports	RS-232, USB
Power Supply	100-240 VAC, 50/60 Hz
Operating Temperature	0°C to 50°C (32°F to 122°F)
Processor	400 MHz ARM11
Memory	128 MB Flash
Display	128 x 64 pixel LCD with backlight
Connectivity	Dial-up, Ethernet
Card Readers	EMV chip
Contactless	Optional
Printer	Integrated thermal printer
Security	PCI PTS
SAM Slots	3
Compliance	EMV Level 1 & 2, RoHS
