4.7 Output configuration
The LD8 is capable of outputting VERIPOS RTCM data and a selection of message formats via the following:
• Serial outputs are available for reference within commands or selected in the WebUI by using ‘COM1’,
‘COM2’ and ‘COM3’.
• TCP/IP output can be established to one of three ports: 3001, 3002 or 3003. These are available for
reference within commands or selected in the WebUI by using ‘COM1’, ‘COM2’ and ‘COM3’ respectively.
Only one connection can be established to each port.
• USB outputs are available for reference within commands or selected in the WebUI by using ‘USB1’,
‘USB2’ and ‘USB3’. Only one connection can be established to each port.
The available LD8 message types and the associated command variable to use when referencing each type
within the WebUI or terminal are shown below:
