Configuration and operation
LD8 Operations Manual 28
4.8 Input configuration
The LD8 is capable of utilising corrections from external sources of VERIPOS RTCM (RTCM v2, RTCM v3 or
CMR) and RTK correction data.
Inputting external VERIPOS RTCM via terminal
To input external corrections, it is required to issue two commands to the unit. These two commands will configure
the required baud rate of input and then set the port for decoding of VERIPOS RTCM data. These commands
are SERIALCONFIG and INTERFACEMODE.
The example commands below show configuration of COM1 for input of VERIPOS RTCM data, with a baud rate
of 115200:
SERIALCONFIG COM1 115200 N 8 1 N OFF
INTERFACEMODE COM1 VERIPOS_RTCM NOVATEL ON
The LD8 is preconfigured to receive RTK corrections. Only port and interface mode settings need to be applied.
