See “Supported Fibre Channel port configuration for the NetBackup 5240 appliances”
on page 43.
About the HBA port mode configuration table
The port mode configuration table shows the details of the HBA ports that can be
used for Fibre Transport Deduplication.
Fibre Transport Deduplication is a feature that enables you to use an appliance as
a target host for optimized duplication and Auto Image Replication.
Note: The HBA port mode configuration table only shows information of the HBA
ports for Fibre Transport Deduplication. The ports that are reserved for SAN Client
Fibre Transport are not shown in this table.
You can configure an HBA port in the table to be in target mode or standard initiator
mode.
Table 4-2 describes the HBA port mode configuration table.
Table 4-2
HBA port mode configuration
DescriptionColumn Name
This column shows the slot number of the HBA card on this
appliance.
Slot
This column shows the port number of the HBA ports.Port
This column shows whether the HBA port is connected to
a fabric switch or another port.
The link status on an HBA port can be the following:
■ up - connected
■ down - not connected
Link Status
This column shows the port WWN. You can use the port
WWN to identify a port on the appliance.
World Wide Name (WWN)
61Configuring Fibre Transport on the appliance
Settings > Network > Fibre Transport
