Vermont Castings UVS27M Homeowner's Installation And Operating Manual

14
UVS27 Vent-Free Gas Heater
20007068
3. Lay the screen and top grille in place.
This completes assembly of the Stardance Freestand-
ing and Pinnacle Hearthmount shells.
ST113a
Hearthmount assy
4/20/99 djt
ST113a
Bottom Tabs engage notch
in the base.
 Engage the Hearthmount Front with the notch in the
bse of each side plate.
ST114a
top install
12/18/03 djt
Grille
Levelling
Screws
ST114b
 Install the Top Plate and Grille.
Screen
