Vernacare COMPACT+ - Plumbing Loom Kit; Pneumatic Tubing & Fittings Kit

Vernacare Compact Plus Technical Manual-Revision 2-Issued by N.Shields 14.2.2020
Page | 29
5.10. Plumbing Loom Kit
5.11. Pneumatic Tubing & Fittings Kit
REF
PART DESCRIPTION
KIT NUMBER
ITEM NUMBER
9210308
1
Mini Hose Clamps 7-9mm S/S
9210157
2
Mikalor Clips 40-60mm
9210160
3
Restrictor Disc
9210030
4
(x2) 15-6-15 Norma ‘T’
9200943
5
6-5 Plastic Reducer
9210164
5
Size 31 Jeppe Clips
9210168
7
25mm PVC Elbow
9210169
8
FBS Clips
9210170
9
15mm PVC Elbow
9210174
10
31 OD 24 ID PVC Tube (various)
N/A
11
22 OD 16 ID PVC Tube (various)
N/A
12
9 OD 5.5 ID PVC Tube (various)
N/A
13
11 OD 7.5 ID PVC Tube (various)
N/A
14
16 OD 12 ID Silicone Tube (various)
N/A
15
18 OD 12 ID Silicone Tube (various)
N/A
16
6 OD 4 ID PVC Tube (various)
N/A
17
ABA Mini Hose Clips Size 11
9210095
18
ABA Mini Hose Clips Size 14
9210096
REF
PART DESCRIPTION
KIT NUMBER
ITEM NUMBER
9210309
1
(x1) ¼” BSP (M) x 6 Swivel Elbow
9210157
2
(x2) 3/2 Valve
9210181
3
(x3) 6mm PIF Tee Connector
9210183
4
(x2) 6mm 1/8” BSP PIF 90’ Elbow
9210186
5
(x2) SMC (F) R1/8 x 6 Male Elbow
9210187
6
(x2) SMC Check Valve 6mm
9210188
7
(x2) 6mm PIF Elbow Connector
9210189
8
(x2) SMC - PSPP Adapter (1/4”to 6mm)
9210190
9
6mm Nylon Tubing (various lengths)
N/A
