Vernacare Vortex - Page 28

28
12 Electrical Circuit
REF
PART DESCRIPTION
ITEM NUMBER
1
PCB
9200820
2
Water Pump
9200529
3
Power Supply Unit 230V (UK)
9200920
4
Display Screen
9200819
5
Low Water Sensor
9200202
6
Tank Level Switch (Deodoriser)
9200208
7
Foot Sensor
9200681
8
Start Switch Keypad
9200534
9
Lid Sensor
9200691
10
Power Supply Unit 110v (Outside UK)
9200921
11
Auto Start Jumper Plug
9200646
PART DESCRIPTION
KIT NUMBER
Interlock Interface Cable Kit
9207018
Solenoid Diode Kit
9207019
Water & Disinfectant Cable Kit
9207020
PCB Power Cable Kit
9207022
Water Pump Cable Kit
9207023
Sheathed Data Cable (to be used with 9200920 & 9200921)
9207029
Installation Kit
9207025
