At a Glanceïï5
1 At a Glance
The Versa Cloud Services Gateway (CSG) 700 series appliances deliver highly secure site-to-site data connectivity to
0*))+!*"!&2*0&7"!20&+"00"0+!1,%,*",##& "0%"0"--)&+ "0-/,3&!"1%"#,)),4&+$#"12/"0ï
 Unified board design that supports different CPUs and memory sizes
 Up to 10 Ethernet ports including:
 ,2/2&)1&+}&$&1-"/0" ,+!¡¢1%"/+"1,3"/ ,--"/¡,¢-,/10ï
 Two 1-GB EoC or SFP ports, available through separate interfaces
 ,2/},4&1%,4"/,3"/1%"/+"1¡,¢-,/10ï3&))"&#"14,/(+1"/# "/!¡¢
module is installed
 +!21,04&1 %)"ïEoC ports
 Two USB ports for plugging in external LTE or WiFi modems
 PoE source support on four Ethernet ports
 Two built-in wireless slots
 GPS connector for geographical location
 External AC power supply
 "+0&+$1,+0" 2/&16), (1,-%60& ))6), (!,4+1%"--)&+ "ï
 Fanless design
 Fixed chassis with no field-replaceable parts
 "0(1,-*,2+1,// (*,2+1)"&+}/ (
1.1 CSG700 Appliance Models
The CSG700 appliances are available in the following models:
 CSG730
 CSG750
 CSG770
The CSG 700 appliance models differ only in CPU, memory, and storage size. See Table 1.
Table 1: CSG700 Appliance Models
CSG Appliance
Model
CPU Memory Storage
CSG730 Intel Denverton with 2
cores
4 GB DRAM 32 GB
CSG750 Intel Denverton with 4
cores
8 GB DRAM 64 GB
CSG770 Intel Denverton with 8
cores
16 GB DRAM 128 GB
1.2 Chassis Views
Figure 1 and Figure 2 show the front and rear panels of the CSG730 appliance. The panels for the CSG750 and
CSG770 appliances are identical to the CSG730 appliance.
Note: The front panel is the side of the appliance with the SIM slots and two LEDs, for status and power. This is
the side that is visible when you install the appliance in an office environment. The rear panel has the power and
