4.4 View Converter Slots Status
Select [4] from the setup menu for current status of MCs in the chassis. The slot status are shown as follows:
-----------------------------------------------------------------------------------------------------------------------------------------
Slot Port Media Speed Duplex Link Slot Port Media Speed Duplex Link RTP
01 A TX 100M Full Up 01 B FX 100M Full Up Up
02 A TX 100M Full Up 02 B FX 100M Full Up Up
03 A TX 100M Full Up 03 B FX 100M Full Up Up
04 A TX 100M Full Up 04 B FX 100M Full Up Up
05 A TX 100M Full Up 05 B FX 100M Full Up Up
06 A TX 100M Full Up 06 B FX 100M Full Up N/A
07 A TX 100M Full Up 07 B FX 100M Full Up N/A
08 A TX 100M Full Up 08 B FX 100M Full Up N/A
09 A TX 100M Full Up 09 B FX 100M Full Up N/A
10 A TX 100M Full Up 10 B FX 100M Full Up N/A
11 A TX 100M Full Up 11 B FX 100M Full Up N/A
12 A TX 100M Full Up 12 B FX 100M Full Up -
13 A TX 100M Full Up 13 B FX 100M Full Up -
14 A TX 100M Full Up 14 B FX 100M Full Up -
15 A TX 100M Full Up 15 B FX 100M Full Up -
16 A TX 100M Full Up 16 B FX 100M Full Up -
-----------------------------------------------------------------------------------------------------------------------------------------
The slot status definitions are:
Column States
Interpretation
Slot 01-16 Slot position in the chassis
Slot #1 - slot #16 are for MC
Port N/A No module is installed in slot
A Upper port of the module in slot
B Lower port of the module in slot
Media N/A No MC is installed in slot.
TX 10BASE-T, 10/100BASE-TX port type
FX 100BASE-FX port type
Speed N/A No MC is installed in slot
10M 10Mbps
100M 100Mbps
Duplex N/A No MC is installed in slot
Full Full duplex
Half Half duplex
Link N/A No MC is installed in slot
Up Link up
Down Link down
RTP * N/A Status not available
Up Remote MC TP link up
---- MC in slot is not M727xS
• RTP: Remote MC TP link status monitoring is available only when M727xS in the chassis is connected to a
remote M727xS through a fiber link.
